Highlights of PNC660
MCX SERVICE
Compliant with 3GPP Release 15 standards, the PNC660 supports MCPTT (Mission-Critical Push-to-Talk), MCVideo, and MCData, enabling seamless mission-critical voice, video, and data communication over 5G and LTE networks.
UNMATCHED SECURITY
The PNC660 integrates multi-layered protection, featuring an independent security chip (IC/COS CC EAL5+), robust encryption, and advanced key management. This ensures maximum data and communication security for high-sensitivity operations.
PERSONNEL SAFETY
The PNC660 enhances workforce safety with Man-Down Detection and Lone Worker Mode, automatically alerting dispatch during emergencies. Covert Mode disables alerts for discreet operations, while Confidential Mode deactivates GPS, mic, and camera to prevent monitoring.
POWERFUL PERFORMANCE
Driven by an 8-core 2.7 GHz processor, the PNC660 delivers smooth multitasking and responsiveness. Its 5,000 mAh detachable battery supports full-day use, while the 33W fast charger restores power in just 1.5 hours.
USER-CENTRIC DESIGN
Built for ease of use, the PNC660 features a Secure Key for activating security modes, a Smart Key for quick actions, and dual Type-C ports for simultaneous charging and accessory use. A customizable widget allows instant access to PoC groups.
RUGGED DURABILITY
Reliability is built in. The PNC660 is IP68-rated, drop-tested to 1.5 meters, and passes over 40 rigorous durability tests — including 400,000 key presses — ensuring consistent performance in the harshest environments.
Specifications of PNC660
LTE
2G: 850/900/1800/1900
WCDMA: B1/B2/B4/B5/B8
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B26/B28 (Full Band)/B66/B68/B71
LTE-TDD: B34/B38/B39/B40/B41 (2496~2690 MHz)/B42/B43/B48
NR: N1/N2/N3/N5/N7/N8/N12/N20/N28/N38/N40/N41/N48/N66/N71/N77/N78/N79
HPUE: B41/B42/N41/N78/N79
4×4 MIMO: N41/N77/N78/N79
NR 2T4R: N41/N77/N78/N79
WLAN: Support 802.11 a/b/g/n/ac/ax/e/k/r/v, Wi-Fi 6E, Wi-Fi 5; Support max 16 connections hotspot; Support DL 2×2 MIMO
NFC: Support
Positioning: AGPS (L1 & L5 Dual-frequency)
Dimensions (H×W×D): 166.6mm × 77.6mm × 14.3mm
Weight: 280g
Operating System: Android 14
Processor: 8-Core Processor & Independent Security Encryption Chip
Memory: RAM 8GB; ROM 128GB / 256GB with 1 × Micro SD (Supports 1024GB Expansion)
Sensors: Fingerprint Sensor, Accelerometer, Gyroscope, Geomagnetic Sensor, Proximity & Light Sensor, Barometer
Peripheral Interface
-
Bottom: Type-C 3.1 Gen2 (Supports Digital Headset, Serial Port, OTG, 33W Fast Charging, Overheat Protection)
-
Side: Type-C (Supports USB 2.0, Charging Warning, Analog Headset, Supports Hytera PTT Headset)
Display: 6.3-inch FHD 1080×2340 Waterdrop Display; Supports Wet-Hand Operation and Glove Mode
Card Slots: Nano ×2 (Supports Dual 5G Standby, Single Active); Supports eSIM
Camera
-
Number of Cameras: 3 (Rear ×2, Front ×1)
-
Rear Main Camera: 50MP PDAF Autofocus
-
Rear Secondary Camera: 8MP Wide-Angle (FOV 120°)
-
Front Camera: 13MP
-
Flashlight: Dual Flashlights
Input: 2 (Dual-Mic Noise Reduction)
Output: 2 (Top Speaker ×1, Bottom Speaker ×1), Loudness: 102dB @ 5cm
File Types: MP3, AACPlus, eAAC, AMR-NB, AMR-WB, G.711, Windows Media Audio (WMA) 9/10 Pro
Video Encoding Technology: P0, H.264 (BP/MP/HP), SP/ASP, DivX, 4x/5x/6x, VP9 (8-bit), H.265 (MP)
Image File Types: JPG, GIF, BMP, PNG, WebP
Video Resolutions and Frames Per Second: 4K @ 30fps
Operating Temperature: -20℃ to +60℃
Storage Temperature: -30℃ to +70℃
Dust & Water Protection: IP68
Vibration, Drop & Shock: 1.5m
